SunEnergyXT 500 PRO AC Core

The powerful retrofit storage system

5-90 kWh capacity

min. 2,400 W output

bidirectional inverter

Simply connect, activate AC coupling, and start saving.

Here is how independent test magazines rate our 500 series:

SunEnergyXT 500 PRO rated "very good" in the connect hands-on test

"More than just a balcony storage unit" – under this title, the specialist magazine connect tested our SunEnergyXT 500 PRO in detail and awarded it the overall rating "Very good".

The connect editorial team particularly highlighted the following features:

  • Fast and precise zero feed-in: The 500 PRO responds to changes in power demand within a few seconds, both with local control and in cloud mode.
  • Well-designed app and intelligent control: The user-friendly SunEnergyXT app impresses with versatile operating strategies, including the use of dynamic electricity tariffs and demand-based feed-in.
  • Local control without cloud: Thanks to the Home Assistant integration provided by SunEnergyXT, the storage unit can be controlled completely locally and integrated into existing home automations.
  • High performance and flexible scalability: With 5 kWh capacity, four MPPT inputs and 800 W or 2,400 W feed-in power, the 500 PRO offers versatile applications – from balcony power plants to larger PV installations.
  • Practical backup power function and comprehensive safety: The editors praise the fast switchover during power outages, the robust aluminium housing and the eight-level protection concept.
Read the full connect hands-on test

SunEnergyXT 500 rated "VERY GOOD" in the COMPUTER BILD hands-on review

"Significantly more than a small storage unit: In the hands-on test, the SunEnergyXT 500 clearly stands out from many typical balcony solar storage systems. The system is larger, sturdier, and considerably more ambitious than many compact solutions, and in return, it offers noticeably more capacity and expansion potential."

The editor’s summary: "In our hands-on review, the system impressed with high-quality design, large capacity, and fast response time."

To the COMPUTER BILD review

SunEnergyXT Shines in c't Magazine's Comparison Test: (XXL) Battery Storage for Balcony Solar Systems

The SunEnergyXT 500 was the only one of the four tested storage systems in this comparison to receive a positive or very positive rating in every single one of the four categories (installation, features, operation, and power regulation).

The editorial team highlighted these points as particularly positive:

  • Precise zero feed-in mode: In combination with a Shelly Pro 3EM, the 500 PRO was able to nearly balance out a modeled load curve with a latency of under two seconds. Along with only one other storage system, this is the fastest response time in the test field.
  • Design: The editorial team highly appreciated the rock-solid quality and visually appealing product design.
  • Scalability: None of the other tested storage systems could match this level of capacity scaling: Up to 270 kWh across multiple towers.
  • High service life: Thanks to a battery-friendly maximum charging current of 0.5 C (equivalent to half the nominal capacity), the cells are specified for >10,000 charge cycles (test conditions: 25 °C ±2 °C, 80 % DoD, 0.5C/0.5C, remaining capacity >70 %).
Read the full c't magazine comparison test (subscription required)

Anker Solarbank 4 Pro vs. SunEnergyXT 500 PRO: The Direct Comparison at BILD.de

In a head-to-head test of 5 kWh balcony power station storage systems, our 500 PRO was compared against a similar, recently launched alternative in a detailed buyer's guide review. The key takeaways:

  • Tied on efficiency: Both 5 kWh storage units delivered strong results with 95% real-world efficiency
  • Smoother zero feed-in: Especially under heavy load spikes, the SunEnergyXT 500 PRO adjusted faster and more evenly, showing less oscillation.
  • Better in low light: At low PV input power (e.g. weak morning/evening light), the 500 PRO already registered small, visible outputs on multiple inputs, while the Solarbank 4 Pro showed 0 W.
  • Comparable backup power: With 2,400 W, the external AC socket of the 500 PRO delivers slightly less power than the Solarbank 4 Pro (2,500 W), but the SunEnergyXT switched to UPS mode more seamlessly without interruption when disconnected from the grid.
  • Different app priorities: BILD rated the Anker app as somewhat more modern but occasionally nested. The SunEnergyXT app impressed with more detailed technical readings.

Editorial verdict: "SunEnergyXT scores points (...) where it matters most in everyday use: earlier PV start in low light and smoother zero feed-in in the hairdryer test."

Read the full BILD.de review: Anker Solarbank 4 Pro vs. SunEnergyXT 500 PRO (2026)

SunEnergyXT 500 PRO on heise online: App control, local Home Assistant integration, and zero-grid feeding tested

The editorial team at heise online took a close look at our 5 kWh storage system, focusing particularly on installation, app control, local control via Home Assistant, zero-grid feeding, yield, efficiency, and value for money. Their conclusion:

  • Easy setup and ample capacity with 5 kWh, which especially makes sense when using more than 3 solar panels.
  • App control with multiple feed-in strategies, including the Dynamic Tariff Strategy as an interesting alternative for users with a smart metering system (iMsys): It allows them to cost-effectively charge the storage unit directly from the grid even during the night or darker time of the year.
  • Particularly noteworthy is the Home Assistant integration, which enables local, cloud-free control.
  • Satisfactory response to load changes within just a few seconds response time.
  • IP65 outdoor rating with excellent heat resistance thanks to passive cooling, which performed well without any loss of performance even during the heatwave in June (2026).
  • Competitive pricing, currently around 20% cheaper than the Anker Solarbank 4.
Read the full heise online review

Why should I retrofit my PV system with a storage unit?

Many existing photovoltaic systems produce plenty of power during the day - exactly when household consumption is usually lowest. Without storage, this valuable solar power flows into the grid for an ever-shrinking feed-in tariff, while electricity prices keep rising unpredictably.

An AC-coupled retrofit storage system is the easiest way to unlock the full potential of your existing PV system:

Sustainably reduce your electricity costs

Use the power you generate yourself in the evening and at night, instead of buying expensive electricity from your utility provider.

Double your self-consumption

Increase your self-consumption rate from 30% to as much as 70-80%, depending on your system and consumption. And all that with 10,000+ cycles for at least 10 years.

Effortless integration

An AC storage system connects directly to your existing AC power network. Your existing PV system and inverter remain completely unchanged - retrofitting couldn't be any easier.

Full flexibility

Regardless of the manufacturer or age of your existing system - thanks to AC coupling, the retrofit always fits and can be tailored exactly to your needs.

In an essence: you already have the solar system on your roof - with a retrofit storage unit, you can finally get the maximum out of your investment.

Installation via AC coupling - it's this easy:

STEP 1

Have the storage system connected

STEP 2

Download our app

STEP 3

Link a smart meter in the app (currently compatible with Shelly (Pro) 3EM and EM-50, EcoTracker IR and P1, and bitShake)

STEP 4

Automatically store your surplus PV power and start saving

Our Powerful All-in-One Device

Most solar storage systems consist of individual, separate components. The SunEnergyXT 500 series combines everything in one device.

2,400 W Bidirectional Inverter

Stores excess power from your home grid at up to 2,400 W and releases it intelligently whenever needed.

5 kWh LFP Battery

Premium 314 Ah EVE cells. Enough to power an average household through the night.

4x 625 W MPPT Solar Charge Controllers (hardware-ready)

Can be activated later via a software upgrade if needed, allowing up to 8 additional solar modules to be connected directly.

One system: flexibly scalable. Configure your storage exactly to your needs.

RECOMMENDED STORAGE CAPACITY

20

kWh

TOWER 1
SYSTEM POWER

GRID FEED-IN

2.4 kW

BACKUP OUTPUT

2.4 kW

AC INPUT POWER

2,400 W

* Grows by 2.4 kW with each additional head unit.

MAX. OUTPUT CURRENT

10.6 A

Your installed PV capacity

10 kWp

1 kWp 22 kWp

Your consumption profile

Expansion unit

MAX. 15

NO. OF UNITS +3 (5 kWh/unit)
3 EXPANSION UNITSMAX: 5

More than just capacity. A new dimension of energy scaling.

Why just expand your storage when you can multiply your output power as well? Discover the world's first system featuring Multi-Head Technology: Scale capacity, MPPT input, and output power simultaneously.

The end of compromises: Multi- Head Parallel Connection.

Most systems only include expansion units that increase storage capacity (kWh), while inverter output power remains the bottleneck. Our system breaks through this limit. By cascading multiple head units, your system grows in every respect:

Double / Triple Output Power

Scale from 2.4 kW to 4.8 kW, and up to an impressive 7.2 kW (32 A), also in off-grid operation.

Input Power Booster

More head units also mean more input power. Maximize your PV yield, even with larger roof systems.

Limitless Flexibility

Stack multiple head units easily using our custom mounting bracket, or place them separately accross your home. Each head unit can also be individually expanded with additional expansion units.

  • 7,200 W Solar Input Power

    With three head units, benefit from the full 7,200 W of usable solar input power.

  • Maximum Power

    Up to 7.2 kW (32 A) output power - powerful enough for demanding household appliances.

  • Reliable Energy Independence

    Multiple head units give you even more backup power and therefore the highest possible failsafe reliability for your home.

8-layered Safety for Your Home

Fully protected from the cell to the casing – with the eight-stage SunEnergyXT storage protection concept.

1

Premium-quality cells – safety starts at the core

High-quality LiFePO₄ cells from EVE Energy, combined with proven manufacturing processes and rigorous quality control, provide a reliable foundation for your safety in everyday use.

Full Control, In Your Pocket.

The SunEnergyXT app allows you to monitor and control your system wherever you are.

Unlock the full potential of your system by downloading the app.

·

Real-Time Monitoring

See PV input, battery status, grid feed-in, and household consumption live.

·

Firmware Updates

Over-the-air updates keep your system current.

·

Zero Feed-In Mode

Automatically adjusts output to match your household demand with a response time as fast as 1 second (local mode).

·

Home Assistant Integration

Local API for advanced smart home users. HA plugin available.

·

UPS Mode Toggle

Enable/disable UPS backup with one tap.

·

Compatible Smart Meters

Shelly 3EM, Shelly Pro 3EM, Shelly EM-50, EcoTracker IR, EcoTracker P1, bitShake.

Technical Specifications

500 PRO AC Core

500 PRO 500

Key Specs at a Glance

Capacity

5 kWh

5 kWh

5 kWh

AC Output 1 - Grid Feed-in (On-Grid)

2,400 W

2,400 W

800 W

AC Output 2 - Backup / Off-Grid Outlet

2,400 W

2,400 W

2,400 W

MPPT Inputs

4× 625 W**Usage limited: The MPPTs can be activated via a paid upgrade

4× 625 W

4× 625 W

UPS Switchover Time

≤10 ms

≤10 ms

≤10 ms

Outdoor Protection

IP65

IP65

IP65

Charge Cycles

10,000+

10,000+

10,000+

Warranty

10-Year

10-Year

10-Year

DIY Installation

Specialised companies only

Specialised companies only

Possible

General Specifications

Operating temperature

-20°C to +55°C (heating system: charge/discharge down to -20°C, automatic heating below 0°C)

-20°C to +55°C (heating system: charge/discharge down to -20°C, automatic heating below 0°C)

-20°C to +55°C (heating system: charge/discharge down to -20°C, automatic heating below 0°C)

Storage temperature

-30°C to +65°C

-30°C to +65°C

-30°C to +65°C

Main unit dimensions (L×W×H)

536 × 314.7 × 307 mm

536 × 314.7 × 307 mm

536 × 314.7 × 307 mm

Main unit weight

58 kg

58 kg

58 kg

Protection rating

IP65 (outdoor suitable)

IP65 (outdoor suitable)

IP65 (outdoor suitable)

Cooling method

Passive (natural convection, fanless)

Passive (natural convection, fanless)

Passive (natural convection, fanless)

Communication

Wi-Fi

Wi-Fi

Wi-Fi

Monitoring

SunEnergyXT App

SunEnergyXT App

SunEnergyXT App

Certifications & Safety Standards

IEC 62109-1/2, IEC 62619, IEC 60730, IEC 61000, EN 18031, VDE 4105, UN38.3

IEC 62109-1/2, IEC 62619, IEC 60730, IEC 61000, EN 18031, VDE 4105, UN38.3

IEC 62109-1/2, IEC 62619, IEC 60730, IEC 61000, EN 18031, VDE 4105, UN38.3

Battery Pack (16V 314Ah LFP)

Battery voltage range

12.5 V – 18.25 V

12.5 V – 18.25 V

12.5 V – 18.25 V

Nominal voltage

16 V

16 V

16 V

Max. continuous discharge current

157 A

157 A

157 A

Battery capacity (nominal)

5,024 Wh

5,024 Wh

5,024 Wh

Usable capacity

4.8 kWh

4.8 kWh

4.8 kWh

Battery current limiter module

5 A

5 A

5 A

Max. parallel battery packs

6 (1x head unit + 5 expansion units)

6 (1x head unit + 5 expansion units)

6 (1x head unit + 5 expansion units)

Battery pack weight

58 kg

58 kg

58 kg

Battery pack dimensions (L×W×H)

536 × 314.7 × 242 mm

536 × 314.7 × 242 mm

536 × 314.7 × 242 mm

Battery cell manufacturer

EVE Energy

EVE Energy

EVE Energy

Charge cycles

>10,000 (at 25°C±2°C, 80% DoD, 0.5C/0.5C, EoL >70%)

>10,000 (at 25°C±2°C, 80% DoD, 0.5C/0.5C, EoL >70%)

>10,000 (at 25°C±2°C, 80% DoD, 0.5C/0.5C, EoL >70%)

Battery certification

UN38.3

UN38.3

UN38.3

Bidirectional Inverter — On-Grid Mode

Grid type

Single-phase, two-wire (L, N) + PE

Single-phase, two-wire (L, N) + PE

Single-phase, two-wire (L, N) + PE

Grid-coupled AC power

2,400 W

2,400 W

800 W

Rated charge power

2,400 W

2,400 W

2,400 W

Rated output voltage

230 VAC / 184–253 VAC

230 VAC / 184–253 VAC

230 VAC / 184–253 VAC

Rated output current

10.5 A

10.5 A

10.5 A

Rated output current (alternative value)

10 A

10 A

10 A

Rated frequency range

50 Hz / 48–52 Hz

50 Hz / 48–52 Hz

50 Hz / 48–52 Hz

Bidirectional Inverter — Off-Grid Mode

Output type

Single-phase AC output

Single-phase AC output

Single-phase AC output

Rated AC output power

2,400 VA

2,400 VA

2,400 VA

Rated output voltage

230 VAC / 225–235 VAC

230 VAC / 225–235 VAC

230 VAC / 225–235 VAC

Rated output current

10.5 A

10.5 A

10.5 A

UPS switchover time

≤10 ms

≤10 ms

≤10 ms

Load compatibility

Common household appliances (power saws, AC units, microwaves, etc.)

Common household appliances (power saws, AC units, microwaves, etc.)

Common household appliances (power saws, AC units, microwaves, etc.)

Parallel operation

Up to 3 units (optional) / Three-phase (coming soon)

Up to 3 units (optional) / Three-phase (coming soon)

Up to 3 units (optional) / Three-phase (coming soon)

PV / MPPT Input

MPPT output power

-

625 W per channel

625 W per channel

Number of MPPT channels

-

4

4

Max. DC input voltage

-

100 V

100 V

MPPT operating voltage range

-

20–60 V

20–60 V

Start voltage

-

20 V

20 V

Max. input current

-

22 A × 4

22 A × 4

Max. short circuit current

-

25 A × 4

25 A × 4

Efficiency / Performance

Max. inverter efficiency

95%

95%

95%

Max. inverter efficiency (peak)

95.25%

95.25%

95.25%

Grid charge efficiency

94.25%

94.25%

94.25%

Max. PV charge efficiency

96.82%

96.82%

96.82%

Max. round-trip efficiency

85%

85%

85%

Battery-to-grid efficiency

94.12%

94.12%

94.12%

MPPT static tracking accuracy

99.99%

99.99%

99.99%

Robust Housing. Compact Design.

Although the SunEnergyXT 500 series is a robust powerhouse made of durable materials, its compact dimensions allow for easy installation in nearly any environment.

Head Unit

536 × 379 × 307 mm

Expansion Unit

536 × 314 × 242 mm

Head Unit

58 kg

Expansion Unit

43.5 kg

Passive cooling, no fans, silent operation

IP65 rated for outdoor installation (-20°C to +55°C)

1.5 mm galvanised steel housing & internal aluminium alloy

USER MANUALDATASHEET

Choose Your System Components

SunEnergyXT 500 PRO AC Core

Head Unit (5 kWh)

SunEnergyXT 500 PRO AC Core

Price: 1,149€

Head & Expansion Unit (10 kWh)

SunEnergyXT 500 PRO AC Core

+ 1x SunEnergyXT B500

Price: 2,148€

Complete System (30 kWh)

SunEnergyXT 500 PRO AC Core

+ 5x SunEnergyXT B500

Price: 6,144€

BUY NOW

Now available for pre-order at the following partner shops - simply click on the logo and go straight to their offers:

FAQ

Yes. The SunEnergyXT 500 PRO AC Core all-in-one home storage system delivers up to 2,400 W of total output power. For example, if 800 W is being fed into the home grid, up to 1,600 W remain available via the integrated backup socket, without any manual switching or special mode required.

The SunEnergyXT 500 PRO AC Core functions as a home storage system with backup power supply: the backup socket is always active when in use. If the battery is depleted, the system automatically switches to grid power, if available.

No, the SunEnergyXT 500 PRO with 2,400 W output power must always be installed by a certified electrician and registered with the grid operator as well as the market master data register (MaStR) in Germany.

Installers have several options for the grid connection: specialist retailers offer cables with an open end for a fixed connection, cables with a Wieland plug, and also high-current cables (CEE, 5-pin, 32 A) for parallel operation of multiple head units. Depending on the cable, available lengths range from 3m to 15m.

SunEnergyXT 500 (800 VA): Complies with the German VDE-AR-N 4105:2026-3 norm for simplified registration by non-professionals with the grid operator. Requirement: connection via an energy socket (e.g. a Wieland socket). A standard earthed (Schuko) plug alone is not compliant. If no energy socket is installed yet, installation by a certified electrician is required.

SunEnergyXT 500 PRO and 500 PRO AC Core (2,400 W): Installation by a certified electrician is required. From a charging capacity of 4.2 kW (e.g. 2× PRO head units), §14a EnWG also applies, allowing for grid operator control.

A smart meter gateway (iMSys) is only mandatory for larger system expansions. Registration with the market master data register (MaStR) and the grid operator is required in any case.

Yes. On the hardware side, every 500 PRO AC Core is already equipped with four high-performance MPPT solar charge controllers (625 W each). These can be flexibly unlocked at any time via an in-app upgrade. Once activated, you can connect up to 8 solar modules (with a max. DC input voltage of 100 V per MPPT) directly to your head storage unit.

How to upgrade to the 500 PRO: You can activate the MPPTs directly within the app. After paying a one-time service fee of €299 (per 500 PRO AC Core head storage unit), you will receive an individual activation code to unlock the MPPTs on your device immediately.

This allows you to keep all expansion options open when purchasing the 500 PRO AC Core, paying for the solar charge controller functionality only when you are ready to use it.

The entire 500 series offers a local API (via HTTP) as well as full Home Assistant integration for maximum flexibility. In addition, the following energy meters are natively supported: Shelly (Pro) 3EM and EM-50, EcoTracker IR and P1, and bitShake.

Thanks to the open API, integration into existing smart home environments is easily done.

The SunEnergyXT 500 PRO AC Core is designed for outdoor use: protection class IP65 (dust-tight and water jet resistant), operating temperature from −20°C to +55°C, integrated battery heating (automatic heating below 0°C), and a built-in fire suppression cartridge for added safety. Above 45°C, output power is automatically reduced to protect the LFP cells.

Recommendation: install beneath a carport, canopy, or balcony roof to maximize product lifetime.

Yes, on the software side: From launch, the SunEnergyXT 500 PRO AC Core can be operated together with BK215/BK215 Plus products via a multi-zone strategy (cloud-based) or locally through Home Assistant. For this, the SunEnergyXT 500 PRO AC Core is added in its own "space." One energy meter (e.g. Shelly) is sufficient for both systems.

Not directly connectable physically: A direct cable connection between the SunEnergyXT 500 PRO AC Core and the BK215 is not possible. Joint control can be done exclusively via software.

The backup socket for emergency power and UPS mode (switching time under 10 ms) always work, even without an internet connection. Off-grid operation with up to 2,400 W output power per head unit is likewise independent of the internet.

A cloud connection is required for full control via the SunEnergyXT app. Alternatively, local control can be used via the API or Home Assistant.

An internet connection is recommended for the initial setup. The storage system also needs an internet connection for regular firmware updates. A manual update option, e.g. via an external medium, is currently still being evaluated.

The SunEnergyXT 500 PRO AC Core features passive cell balancing.

The SunEnergyXT 500 series uses high-quality 314Ah EVE LFP (lithium iron phosphate) cells and is rated for at least 10,000 charge cycles. With one full cycle per day this corresponds arithmetically to about 27 years under the stated test conditions (25 °C ±2 °C, 80 % DoD, remaining capacity >70 %); actual service life depends on use and ambient conditions. The manufacturer warranty is 10 years.

Privacy Preference

We need your consent before you can continue visiting our website.

We use cookies and other technologies on our website. Some of them are essential, while others help us improve this website and your experience. Personal data may be processed (e.g. IP addresses), e.g. for personalized ads and content or ad and content measurement. For more information about how we use your data, see our privacy policy. You can revoke or adjust your choices at any time under Settings.
